| คุณลักษณะ | รายละเอียด | Attribute | Details |
|---|---|---|---|
| Brand | BOE | Brand | BOE |
| Model | P/NMV238FHM-N51 | Model | P/NMV238FHM-N51 |
| Diagonal Size | 23.8″ | Diagonal Size | 23.8″ |
| Panel Type | a-Si TFT-LCD, LCM | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD | Resolution | 1920(RGB)×1080, FHD |
| Pixel Format | RGB Vertical Stripe | Pixel Format | RGB Vertical Stripe |
| Active Area | 527.04(W)×296.46(H) mm | Active Area | 527.04(W)×296.46(H) mm |
| Outline Dim. | 534.9(H)×306.95(V) ×14(D) mm | Outline Size | 534.9(H)×306.95(V) ×14(D) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) | Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 250 cd/m² (Typ.) | Luminance | 250 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry | View Direction | Symmetry |
| Response Time | 14 (Typ.)(G to G) | Response Time | 14 (Typ.)(G to G) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down | Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down |
| Operating Mode | ADS, Normally Black, Transmissive | Operating Mode | ADS, Normally Black, Transmissive |
| Support Color | 16.7M 100% sRGB | Support Color | 16.7M 100% sRGB |
| Light Source | WLED [4 strings], 30K hours, W/O Driver | Light Source | WLED [4 strings], 30K hours, W/O Driver |
| Weight | 2.20Kgs (Typ.) | Weight | 2.20Kgs (Typ.) |
| Designed For | Desktop Monitor | Designed For | Desktop Monitor |
| Frame Rate | 75Hz | Frame Rate | 75Hz |
| 120Hz (60HZ Input) | Embedded MEMC Circuit | 120Hz (60HZ Input) | Embedded MEMC Circuit |
| 120Hz+120Hz | 120Hz Panel+120Hz Backlight | 120Hz+120Hz | 120Hz Panel+120Hz Backlight |
| 240Hz (60HZ Input) | Embedded MEMC Circuit | 240Hz (60HZ Input) | Embedded MEMC Circuit |
| Touch Panel | Without | Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit), 30 pins Connector | Interface Type | LVDS (2 ch, 8-bit), 30 pins Connector |
| Power Supply | 5.0V (Typ.) | Power Supply | 5.0V (Typ.) |
| Operating Temperature | 0 ~ 50 °C | Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C | Storage Temperature | -20 ~ 60 °C |
📦 จัดส่งทั่วประเทศ
💬 สอบถามข้อมูลเพิ่มเติม หรือ สั่งซื้อติดต่อเราได้เลย! [ 02-933-0022 , 081-318-9844 / LINE: @shoppingpc / shoppingpc.net ]
อะไหล่หน้าจอ 23.8 นิ้ว MV238FHM-N51 : Panel High – Performance Business Monitors
This 23.8-inch display offers excellent clarity and vibrant color reproduction, ideal for high-performance business environments. With Full HD resolution, wide viewing angles, and an anti-glare treatment, this display ensures crisp and clear visuals from all angles. Designed for desktop monitors, it provides a seamless and comfortable viewing experience, whether for office work or entertainment. It is also lightweight, making it easy to incorporate into various setups.
